Surges may be caused by an indirect lightning strike but, the majority are caused by equipment being turned on or off within a facility. These surges damage components costing money to repair or replace as well as create unplanned downtime resulting in unfulfilled orders, missed deadlines, unreliable systems and/or dangerous situations. The GHX Surge Protective Device (SPD) Series for branch circuits safeguards components from transient overvoltage or surges by limiting the fault current to a load or the unit being protected.
The DIN-rail mounted, pluggable module device offers a compact footprint for panel design flexibility as well as a quick and easy installation. With UL and IEC compliance in one component, the Surge Protective Device (SPD) Series reduces inventory needs and simplifies allocation of parts.
The Surge Protective Device (SPD) Series is ideal for power distribution (load centers, transformers, generators), electrical loads (motors, fans, heaters, blowers, ballasts), industrial controls (programable logic controllers, motor controls, variable-frequency drives, proximity sensors, barcoding equipment, machine vision systems), computers and communications (LANs, WANs, intercoms, and fire, security, UPS or building management systems), and HVAC or medical equipment.
To choose the best technology for surge protective devices, we should consider the following technical parameters (include but not limited to): 1. Type of surge protective devices according to EN61643-11/IEC 61643-11 2. Nominal Voltage (Un) 3. Maximum Continuous Operating Voltage (Uc) /Maximum Continuous Operating Voltage for PV System (Ucpv) 4. Voltage Protection Level (Up) 5. Nominal Discharge Current (In) 6. Maximum Discharge […]
The components of a SPD The SPD chiefly consists of (see Fig.1): 1) one or more nonlinear components: the live part (varistor, gas discharge tube, etc.); 2) a thermal protective device (internal disconnector) which protects it from thermal runaway at end of life (SPD with varistor); 3) an indicator which indicates end of life of […]
Knowing individual surge components is helpful to understand, but what drives the standards for SPDs are performance aspects or features for each device. After identifying the power distribution system to which the SPD is to be connected, one should compare different available devices by the following: 1. Maximum Continuous Operating Voltage (MCOV). The MCOV is the […]
