Description
Product Description
Yuelong Electric(GHX) is a large-scale SPD T1 T2 manufacturer and supplier in China. We have been specialized in SPD T1 T2 for many years. Our hot selling SPD T1 T2 products with free sample are popular oversea markt.We look forward to working with you in the future.
It protect to indirect and direct lightning effect or other transient over voltage. SPD design according with GB18802.1/IEC61643-1 standard.
YL2-C50-12.5M 4P Surge Arrester Parameter (Specification):
| YL2-C50-12.5M 4P | |
| SPD classification according to EN61643-11 | Type 1+Type 2 |
| SPD classification according to IEC61643-11 | Classl+ Class Ⅱ |
| Nominal operating voltage Un | 230/400V(50/60Hz) |
| Max. continuous operating a.c. Uc | 320V(50/60Hz) |
| Temporary overvoltage TOV | 385V/5s-withstand |
| Lightning impulse current(10/350μs) limp | 12.5kA |
| Nominal discharge current (8/20μs) In | 20kA |
| Maximum discharge current(8/20μs) Imax | 50kA |
| Voltage protection level Up | ≤1.5kV |
| Short circuit current rating a.c lsccr | 25kArms |
| Max. backup fuse | 160A gG |
| Response time tA | ≤25ns |
| Operating temperature range Tu | -40℃-80℃ |
| Cross-section area(Min.) | 4mm² |
| Cross-section area(Max.) | 35mm² |
| For mounting on | 35mm Din rail |
| Enclosure material | Thermoplastic UL94-V0 |
| Degree of protection | P20 |
| Dimension | 91mm*82 mm*83 mm |
Dimension:
FAQ
Q:When I can receive quotation and detail information after send the enquiry?
A: Reply will be sent in 24hours.
Q:What’s the difference between you and other suppliers?
A: We have our own design box with PC/ABS material.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q:Can I get a sample for test before place order?
A:Of course!
Q:How’s the delivery?Because I really need them is urgently?
A: Samples cost 2-3 days. Bulk order cost 12-15 days.
Q: If i want to release order, what’s the payment method you accept ?
A: We accept T/T, Western union, Trade Assurance.
A: Reply will be sent in 24hours.
Q:What’s the difference between you and other suppliers?
A: We have our own design box with PC/ABS material.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q:Can I get a sample for test before place order?
A:Of course!
Q:How’s the delivery?Because I really need them is urgently?
A: Samples cost 2-3 days. Bulk order cost 12-15 days.
Q: If i want to release order, what’s the payment method you accept ?
A: We accept T/T, Western union, Trade Assurance.
