The IEC 62305 standard parts 1 to 4 (NF EN 62305 parts 1 to 4) reorganizes and updates the standard publications IEC 61024 (series), IEC 61312 (series) and IEC 61663 (series) on lightning protection systems.
Part 1 – General principles
This part presents general information on lightning and its characteristics and general data, and introduces the other documents.
Part 2 – Risk management
This part presents the analysis making it possible to calculate the risk for a structure and to determine the various protection scenarios in order to permit technical and economic optimization.
Part 3 – Physical damage to structures and life hazard
This part describes protection from direct lightning strokes, including the lightning protection system, down-conductor, earth lead, equipotentiality and hence SPD with equipotential bonding (Type 1 SPD).
Part 4 – Electrical and electronic systems within structures
This part describes protection from the induced effects of lightning, including the protection system by SPD (Types 2 and 3), cable shielding, rules for installation of SPD, etc.
This series of standards is supplemented by:
the IEC 61643 series of standards for the definition of surge protection products;
the IEC 60364-4 and -5 series of standards for application of the products in LV electrical installations.
